Technical Specification :
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.40mm / 0.45mm / 0.50mm |
| Length | 3660mm |
| Flange | Two equal flanges of 26mm each |
| Web | Knurled web of 51.5mm |
Application : It is a main supporting member which is suspended from the soffit with raw plug, soffit cleat and MS Flat from the soffit with raw plug, soffit cleat and MS Flat at 1220mm c/c in one row in 1220 apart.
Technical Specification :
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.80mm/0.90mm |
| Length | 3660mm |
| Flange | Two equal flanges of 15mm each |
| Web | 45 mm |
Application :Used on intermediate support to ceiling sections. It is used as a main supporting member at 1220mm c/c and is suspended from the soffit with help of metal plugs and soffit cleat at 1220mm apart.
Technical Specification :
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.40mm / 0.45mm / 0.50mm |
| Length | 3660mm |
| Flange | Two equal flanges of 20mm & 30 each |
| Web | 26 mm |
Application : It is used at the perimeter of the ceiling the on to the wall/partition with the help of nylon sleeves and screw at 610 mm c/c.
Technical Specification :
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.40mm / 0.45mm / 0.50mm |
| Length | 3660mm |
| Flange | Two equal flanges of 25mm x 25mm and 10mm x 25mm |
Application : It is Used with gypsum board steel strapping in the coloum and beam encasement system at the flanges and for fixing the outer layer of a double layer partition at external angles.
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.50mm / 0.55mm |
| Length | 3660mm |
| Flange | Two equal flanges of 36mm & other of 34mm |
| Web | 48mm, 73mm, 98mm |
Technical Specification :
| Basic Steel | Cold Rolled Steel |
| Galvanization | Hot Dip Galvanized (120gsm) |
| Thickness | 0.50mm / 0.55mm |
| Length | 3660mm |
| Flange | Two equal flanges of 32mm |
| Web | 50/75/100mm with a flange of 32mm |
Application : It is used horizontal metal section at the ceiling and floor in metal framed partitions systems.
